McCloskey International have a proven reputation for designing quality, class leading machinery. McCloskey International is now breaking new ground with the introduction of the C50 crusher.

The first of McCloskey's full line of crushers, the C50 Jaw Crusher is continuing McCloskey's focus on quality, durability, and productivity. With a CAT C9 engine, 50'' wide Telsmith Jaw (the widest Jaw in its class), and user friendly control panel with excellent machine diagnostics, the C50 places McCloskey's at the fore of portable crushing machinery.

With class leading material throughput and capacity, the largest stockpile height in its class, and an extended side conveyor as standard, the new C50 crusher continues to push the boundaries of industry performance.

Features, Benefits and Options

• Feeder – Folding hardox hopper mounted over vibrating feeder with integral pre-screen. Auto regulated feeder speed.
• Crusher – True 50'x26' (1270mmx660mm) jaw, built by Telsmith in USA. Forward and reverse hydrostatic drive. Reversible jaw drives. Hydraulic closed side setting.
• Conveyor – Extended 42" main conveyor as standard, giving large stockpile capacity. Conveyor lowers and is easily removable for maintenance.
• Power unit – CAT C9 engine (261kW) with all round access for maintenance. Innovative hydraulic system.
• Colour Control Panel – User friendly waterproof control panel.
• Optional roll in bogie
• Optional Hopper Extension
• Optional Overband Magnet
• Optional Crusher Deflector Plate
• Optional water pump and dust suppression

Specifications

• Power Plant: 350 HP (261 kw) Tier III CAT C9 Engine
• Jaw: 50'' x 26'' (1270mm x 660mm)
• Hopper: 6.8m³ (8.9yd³) Level hopper capacity; 10.2m³ (13.3yd³) Gross hopper capacity
• Transport Height: 11' – 2'' (3.4m)
• Transport Length: 47' – 10'' (14.3m)
• Transport Width: 9' – 6'' (2.9m)
• Weight: 48,000 kg (105,821 lb)
